IPX Series Amplifiers

Networked multi-channel amplification with integrated DSP capabilities for large-scale installation . IPX Series is our top-of-the-line amplifier series for fixed installation — three 4-channel models and one 8-channel model, from 1,250 to 5,000 watts per channel, with Dante audio and FIR-Drive loudspeaker processing for optimized performance. These high-performance amplifiers offer seemingly unlimited power and pristine audio quality and can be configured, controlled and operated with SONICUE Sound System Software.

Product introduction video

IPX Series Amplifiers

Why IPX

Maximum power density of up to 20,000 watts per amp

IPX Series power amplifiers are equipped with several sophisticated Dynacord technologies such as ecoRAIL, which reduces overall power consumption in idle mode of more than 50%. Variable Load Drive (VLD) technology allows allows the available output power per channel to be used at either 4 or 8 Ohms, or via 70 V or 100 V lines in direct drive.

With a total power of up to 20,00 watts per amplifier and integrated IP network (Dante audio and OCA/AES70 control), IPX Series takes minimum rack space. High resolution 96 kHz signal processing, internal analog-to-digital conversion with ultra-low latency, and a superior signal-to-noise ratio yield to maximum performance.

IPX Series

IPX Series	IPX5:4	IPX10:4	IPX10:8	IPX20:4
Channels
Channels	4	4	8	4
Output per channel
Output per channel	1,250 W	2,500 W	1,250 W	5,000 W
Network
Network	Dante audio and OCA/AES70 control	Dante audio and OCA/AES70 control	Dante audio and OCA/AES70 control	Dante audio and OCA/AES70 control
DSP
DSP
Direct Drive
Direct Drive
