COMPACT POWER. FULL CONTROL.

Name: IPX5:4 DSP power amplifier, install
Brand: Dynacord
SKU: F.01U.329.709
Availability: OutOfStock

A networked install amplifier delivering 4 x 1250 W with OMNEO/Dante audio and FIR-Drive processing.

IPX5:4 DSP power amplifier, install

A 4-channel install DSP power amplifier rated 4 x 1250 W, with 96 kHz FIR Drive processing and OCA/Dante networking.

productPage.buybox.findRetailer

productDocuments.preview.title

Get four channels of clean install power without the rack penalty. The IPX5:4 delivers 1250 W per channel, switches each output to Low-Z or 70/100/140/200 V direct drive, and carries 48/96 kHz audio over OMNEO/Dante. FIR-Drive linear-phase filtering, peak and RMS limiters, and impedance load monitoring sit on every output. Signal latency holds at 0.70 ms. Retail, hospitality, worship, mid-size venue — distributed sound that needs real processing in one rack space.

Key features

Four channels, one rack space

1250 W per channel for distributed and foreground sound.

Constant-voltage ready

70/100/140/200 V direct drive per channel, plus Low-Z operation.

Network-native audio

48/96 kHz over OMNEO/Dante on redundant PRIMARY/SECONDARY links.

Linear-phase loudspeaker control

FIR-Drive up to 1025 taps with per-channel limiters.

Protect the install

pilot-tone supervision and impedance monitoring catch a fault automatically.

Cut the standby draw

standby mode keeps the draw under 15 W.

Short introduction

IPX Series Amplifiers

Complete the System

Where this unit fits, and what it pairs with.

productPage.features

Networked install power with the processing on board. The IPX5:4 drives 4 channels 1250 W simultaneously, with a native 96 kHz DSP, FIR Drive up to 1025 taps, and Dante/OCA over OMNEO with fallback for redundancy. Class D output and ecoRAIL keep efficiency high and running costs down, while load monitoring and pilot-tone supervision watch every line. Two rack units. Stadiums, houses of worship, retail, transport hubs, and multi-zone installs that route and process from the amplifier itself.

Multichannel power: 4 channels at 1250W/4 Ohms, 70 V, 100 V, 0r 1800W/2.6 Ohms.
Processing built in: native 96 kHz DSP with FIR Drive up to 1025 taps.
Networked audio: Dante / OCA over OMNEO with fallback for redundant routing.
Watches the system: load monitoring and pilot-tone supervision on every line.
Efficient by design: Class D output with ecoRAIL power management to cut running cost.
ghostPOWER keeps DSP and network running to bridged mainspower switching in mission critical systems
