EVF-1152S/64-FG Arrayable point-source 15" fully-weatherized
EVF-1152S/64-FG Arrayable point-source 15" fully-weatherized
A fully-weatherized, arrayable 15-inch point-source loudspeaker with tight 60° x 40° coverage, in white.
Hang it outdoors and forget about it. The EVF-1152S/64-FG pairs an ND2B 2-inch titanium compression driver on a Constant-Directivity 60° x 40° waveguide with the FEA-optimized SMX2151 15-inch woofer, so vocals stay clear and even at high SPL. The trapezoidal birch enclosure is fiberglass-coated and fitted with a stainless-steel grille and gland-nut panel for full exposure to the elements. The white finish blends into bright facades, plazas, and resorts where black would stand out.
Key features
Disappear into the architecture
white fiberglass-coated birch enclosure with stainless-steel grille.
Aim the energy where it counts
Constant-Directivity 60° x 40° waveguide for narrow, even coverage.
Clear voice at volume
ND2B 2-inch titanium driver and FEA-optimized SMX2151 15-inch woofer keep distortion low.
Switch passive or biamp on site
externally accessible jumper, no enclosure entry needed.
Build any array, add 70/100 V later
mixes with the full EVF and EVH range; optional TK-150 transformer kit for distributed lines.
Hang it your way
22 M10 threaded suspension points rig vertical or horizontal arrays overhead.
productPage.features
Hang it outdoors and forget about it. The EVF-1152S/64-FG pairs an ND2B 2-inch titanium compression driver on a Constant-Directivity 60° x 40° waveguide with the FEA-optimized SMX2151 15-inch woofer, so vocals stay clear and even at high SPL. The trapezoidal birch enclosure is fiberglass-coated and fitted with a stainless-steel grille and gland-nut panel for full exposure to the elements. The white finish blends into bright facades, plazas, and resorts where black would stand out.
- Disappear into the architecture — white fiberglass-coated birch enclosure with stainless-steel grille.
- Aim the energy where it counts — Constant-Directivity 60° x 40° waveguide for narrow, even coverage.
- Clear voice at volume — ND2B 2-inch titanium driver and FEA-optimized SMX2151 15-inch woofer keep distortion low.
- Switch passive or biamp on site — externally accessible jumper, no enclosure entry needed.
- Build any array, add 70/100 V later — mixes with the full EVF and EVH range; optional TK-150 transformer kit for distributed lines.
productPage.info.specs
Acoustic Performance
- Coverage Angle
60 × 40
Identification
- Series / Family
EVF
- productPage.materialNumber
F.01U.206.186
