PUT A LINE ARRAY WHERE A LINE ARRAY SHOULD NOT FIT
XLE181-FGW 2-Way Very Compact Line-Array Element
The most compact XLE element in a weatherized IP55 white build for the installs nobody gets to service.
Put a line array where a line array should not fit. The XLE181-FGW is the weatherized white version of the most compact XLE element: one DVN2080 8-inch neodymium woofer and two ND2S-8 titanium compression drivers through a 120 by 10 degree waveguide, at 17.2 kilograms. The IP55 fiberglass build with hydrophobic grille cloth lives outdoors year round. Fly up to 16 elements on the fully captive aluminum rigging in 1 degree steps, and aim it in LAPS. Stadium concourses, waterparks, transit, fascia and under-balcony fills: real pattern control that faces the weather.
Key features
Features
Put a line array where a line array should not fit. The XLE181-FGW is the weatherized white version of the most compact XLE element: one DVN2080 8-inch neodymium woofer and two ND2S-8 titanium compression drivers through a 120 by 10 degree waveguide, at 17.2 kilograms. The IP55 fiberglass build with hydrophobic grille cloth lives outdoors year round. Fly up to 16 elements on the fully captive aluminum rigging in 1 degree steps, and aim it in LAPS. Stadium concourses, waterparks, transit, fascia and under-balcony fills: real pattern control that faces the weather.
Specifications
Overview & Features
- Configuration
2-way very compact line-array element, bi-amp or full-range
Acoustic Performance
- Max SPL
143
- Frequency response low (-3 dB) (Hz)
90
- Frequency response high (-3 dB) (Hz)
18000
- Frequency Response
90 Hz - 18 kHz
- Frequency Range (-10 dB)
75 Hz - 20 kHz
