EVU-CDNL4 Input panel cover plate, dual NL4 type
EVU-CDNL4 Input panel cover plate, dual NL4 type
A dual NL4-type input cover plate for EVA, EVC, EVF, and EVH install loudspeakers.
Finish the connection the right way. The EVU-CDNL4 swaps in as the input panel cover on EVA, EVC, EVF, and EVH cabinets, giving you two NL4-type connectors in a clean, install-grade plate. Loop through, link cabinets, or wire a dedicated low-Z and bi-amp run — and keep the back of the box tidy when the rig goes up for good.
Key features
Two connections, one plate
dual NL4-type inputs for loop-through and linked runs.
Drops into the family
fits EVA, EVC, EVF, and EVH install loudspeakers.
Install-grade finish
replaces the standard input panel for a clean, permanent look.
Black on order
CDNL4-LB ships in black, order number F.01U.283.495.
Wire with intent
supports low-Z and bi-amp connection schemes on compatible cabinets.
Features
Finish the connection the right way. The EVU-CDNL4 swaps in as the input panel cover on EVA, EVC, EVF, and EVH cabinets, giving you two NL4-type connectors in a clean, install-grade plate. Loop through, link cabinets, or wire a dedicated low-Z and bi-amp run — and keep the back of the box tidy when the rig goes up for good.
- Two connections, one plate — dual NL4-type inputs for loop-through and linked runs.
- Drops into the family — fits EVA, EVC, EVF, and EVH install loudspeakers.
- Install-grade finish — replaces the standard input panel for a clean, permanent look.
- Black on order — CDNL4-LB ships in black, order number F.01U.283.495.
- Wire with intent — supports low-Z and bi-amp connection schemes on compatible cabinets.
Specifications
Acoustic Performance
- Sensitivity (1W/1m)
92 dB (1 W/1 m)
Transducers & Drivers
- LF transducer size (in)
ICT-1-8, 1.3” (33 mm) diaphragm compression driver
Impedance
- LF Impedance
8 ohms (nominal), 6.0 ohms (min.)
Connectivity & I/O
- Connectivity
Single four-pin 12 AWG Phoenix/Euro Block screw-terminals
Protection & Environmental
- Ambient Temperature
IEC 60529
Construction & Materials
- Enclosure
9-ply hardwood plywood with textured paint
