EVH-1152D/96
EVH-1152D/96
A horn-loaded 15-inch coaxial install loudspeaker with rotatable 90° x 60° pattern control.
Aim coverage where the seats are, not where the box happens to hang. The EVH-1152D/96 pairs an SMX2151 15-inch woofer with a DH7N 3-inch titanium compression driver behind a rotatable 90° x 60° waveguide, so you keep tight pattern control down to 500 Hz in any orientation. A 13-ply birch enclosure with EVCoat takes the abuse of a working venue. Houses of worship, theaters, gyms, multipurpose halls — even coverage, clean vocals, room after room.
Key features
Aim the pattern, not the box
rotatable 90° x 60° waveguide holds coverage in any enclosure orientation.
Coaxial clarity
SMX2151 15-inch woofer and DH7N 3-inch titanium driver on one axis, 105 dB sensitivity.
Control where it counts
directivity stays tight down to 500 Hz across the vocal range.
Built for the install
13-ply weather-resistant birch with EVCoat and 28 M10 suspension points.
Wire it your way
Phoenix-style connectors, passive or biamp via the external jumper card, optional TK-150 70/100 V transformer.
Protects its own top end
built-in HF protection circuit keeps the DH7N reliable for the long term.
Features
Aim coverage where the seats are, not where the box happens to hang. The EVH-1152D/96 pairs an SMX2151 15-inch woofer with a DH7N 3-inch titanium compression driver behind a rotatable 90° x 60° waveguide, so you keep tight pattern control down to 500 Hz in any orientation. A 13-ply birch enclosure with EVCoat takes the abuse of a working venue. Houses of worship, theaters, gyms, multipurpose halls — even coverage, clean vocals, room after room.
- Aim the pattern, not the box — rotatable 90° x 60° waveguide holds coverage in any enclosure orientation.
- Coaxial clarity — SMX2151 15-inch woofer and DH7N 3-inch titanium driver on one axis, 105 dB sensitivity.
- Control where it counts — directivity stays tight down to 500 Hz across the vocal range.
- Built for the install — 13-ply weather-resistant birch with EVCoat and 28 M10 suspension points.
- Wire it your way — Phoenix-style connectors, passive or biamp via the external jumper card, optional TK-150 70/100 V transformer.
Specifications
Acoustic Performance
- Frequency Response
60 Hz–17 kHz
- Frequency Range (-10 dB)
50 Hz–20 kHz
- Coverage Angle
90 × 60
- Sensitivity (1W/1m)
105 dB (1 W/1 m)
Transducers & Drivers
- LF transducer size (in)
15
- HF transducer size (in)
3
